Unrivaled Power for the Most Demanding Environments
The BOKK JC100 is a professional-grade, large-frame skid steer built for high-productivity construction, large-scale agriculture, and heavy industrial use. Featuring a nearly 100HP engine and a robust 4-ton chassis, it provides a level of performance that redefines what a compact loader can do.
Key Performance Highlights:
Massive 99.2HP Engine: The JC100 is powered by a high-torque 74kW engine, offering incredible pushing power and the ability to maintain peak hydraulic performance under the most grueling conditions.
1.1 Ton Payload Specialist: Designed to lift and move 1100kg payloads safely and quickly. Its 4000kg self-weight ensures a rock-solid foundation for high-reach operations.
Industry-Leading 2550mm Lift: The extended lift arms provide a 2450mm dumping height, allowing the JC100 to load high-sided articulated trucks and large material hoppers that smaller loaders can’t reach.
Heavy-Duty Traction: Equipped with professional 12-16.5 tires and a high-clearance chassis (205mm), the JC100 masters deep mud, steep slopes, and rocky terrain.
Maximized Efficiency: A larger 0.55 m³ bucket comes standard, moving more cubic meters per hour and significantly reducing fuel consumption per ton of material moved.
Technical Data Sheet for JC100
JC100
Item Data Deadweight (kg) 3800 Bucket capacity (m³) 0.55 High Flow Flux (L/min) 140 Rated power (Kw) 74 Horsepower(HP) 99.16 Operating load (kg) 1100 Tire（track） model 12-16.5 Fuel tank capacity (L) 90 Rated flux (L/min) 75 Max Speed（km/h） 12\18 A, Overall operating height (mm) 4070 B, Height to bucket hinge pin (mm) 3150 C, Hheight to top of cab (mm) 2160 D,Height to bottom of level bucket(mm) 2983 E,Without bucket length（mm） 2880 F, Overall length with bucket(mm) 3580 G, Dumping angle at maximum height(° ) 40 H, Dumping height(mm) 2450 I, Dumping reach(mm) 700 J, Rollback o bucket on ground(° ) 30 K, Rollback of bucket at full height(° ) 104 L, Wheelbase(mm) 1185 M, Ground clearance(mm) 205 N, Angle of departure(° ) 20 O, Front turning radius without bucket(mm) 1278 P, Front tuning radius(mm) 2144 Q, Rear tuning radius(mm) 1857 R, Rear axle to bumper (mm) 1082 S, Tread width (mm) 1500 T, Width (mm) 1880 U, Bucket width (mm) 1880
