Engineered for Professional Landscaping and Narrow-Access Work
The BOKK LY850 provides the perfect balance of a small footprint and high-performance hydraulics. The stand-on design not only reduces the machine’s overall size but also provides the operator with 360-degree visibility and the ability to step on and off quickly—ideal for fast-paced job sites.
World-Class Kubota Power: Equipped with the Kubota D1105 (Euro V / EPA4) engine, the LY850 offers quiet, reliable, and fuel-efficient performance with global service support.
Master of Tight Spaces: With a total width of only 1150mm and a specialized tracked undercarriage, it glides over soft turf with minimal ground pressure while fitting through narrow passages and backyards.
Rugged Vertical Performance: Despite its size, it boasts a 2159mm height to bucket hinge pin, making it more than capable of loading trailers, dumpsters, and raised planters.
Industrial Build Quality: Featuring a 1330kg operating weight and 12kN of traction force, the LY850 handles heavy aggregates and soil with ease, offering a high ROI for rental companies and contractors.
Technical Data Sheet
LY850 Mini Skid Steer Loader
Item Data Operating weight(kg) 1330 Rated load(kg) 400 Bucket capacity(m³) 0.2 Max Speed(km/h) 5.6 Max traction(kN) ≥12 Max breakout(kN) ≥7 Lifting time of
boom(s)7 Engine Manufacturer Kubota Engine Model D1105 Engine Rated power
(kW/rpm)18.2/3000 Engine displacement
(L)1.123 Engine Emssion Standard Euro V/EPA4 Overall operating
height(mm)2800 Height to bucket
hinge pin(mm)2159 Height to top of
cab(mm)1685 Height to bottom of
evel bucket(mm)2831 Without bucket
length(mm)2165 Overall length with
bucket(mm)2831 Dumping angle at
maximum height(°)30 Dumping height(mm) 1685 Dumping reach(mm) 611 Rollback of bucket
on ground(°)30 Rollback of bucket
at full height(°)103 Wheelbase(mm) 1149 Ground clearance
(mm)258 Angle of departure(°) 29 Front turning radius
without bucket(mm)970 Front tuning radius
(mm)1496 Rear tuning radius
(mm)1496 Rear axle to bumper
(mm)910 Tread width (mm) 826 Width(mm) 1006 Bucket width(mm) 1166
