Skip to content- Equipped with 6110, 6108, or turbocharged engine, Shantui 315 torque converter, and Shantui 428 transmission.
- Features a dedicated engineering machinery wheel-side reduction axle and air-over-hydraulic caliper disc brakes.
- Reinforced, thickened, and heavy-duty frame, boom, and bucket for enhanced overall reliability.
- Lowered frame height for improved visibility.
- Overall width ≤ 2.4 meters (with 17.5-25 tires, width ≤ 2 meters with 12.00-24 tires), overall height ≤ 2.55 meters (to the top of the simple canopy), overall length ≤ 6.76 meters.
- Bucket cutting edge made of wear-resistant 400 special steel; bucket width can be customized according to customer requirements.
- Standard equipped with exhaust gas purification water filtration device.
- Optional catalytic converter.
- Optional side dumping device.
- Optional tire protection chains.
| Project | Unit | Parameter |
|---|
| Bucket Capacity | m³ | 1.7 |
| Rated Load | T | 3.5 |
| Machine Weight | T | 10.8 |
| Walking Speed | km/h | 0-35 |
| Forward gear | km/h | Ⅰ 0-7 Ⅱ 7-12.5 |
| Forward gear | km/h | Ⅲ0-21 Ⅳ0-35 |
| Reverse gear | km/h | Ⅰ 0-14 Ⅱ 0-25 |
| Grade Ability | ° | 15° |
| Overall Dimension(LxWxH) | mm | 6760×2000×2550 |
| Wheel Base | mm | 2700 |
| Wheel Tread | mm | 1580 |
| Max.Dumping Height | mm | 2740 |
| Dumping Reach | mm | 1200 |
| Rated Power | KW | 92 |
| Engine model | | YUCHAI |
| Tire Model | | 12.00-24 |
