Skip to content- 4102 or 4108 or 4105 turbocharged engine, 280 type dual variable.
- Special wheel side reduction axle for construction machinery, with pneumatic oil caliper disc brakes.
- The width of the whole machine is ≤ 1.8 meters, the height of the whole machine is ≤ 1.9 meters (up to the size of a simple shed), and the length of the whole machine is ≤ 5.5 meters.
- Narrower, shorter, and shorter, suitable for ultra-low and ultra narrow tunnels.
- Standard 15/70-18 tires, optional 9.75-18 tires (overall width 1.6 meters).
- The bucket blade plate is made of wear-resistant 400 special steel plate.
- The width of the bucket can be customized according to user needs.
- Standard exhaust water filtration device.
- Optional imported three-way catalyst.
- Optional side release device.
- Optional tire protection chain.
| Project | Unit | Parameter |
|---|
| Bucket Capacity | m³ | 0.8-1.0 |
| Rated Load | T | 2.0 |
| Machine Weight | T | 7.0 |
| Max.Digging Force | KN | 48 |
| Max.Tractive Force | KN | 30 |
| Walking Speed | km/h | 0-13 |
| Forward gear | km/h | Ⅰ 0-5 Ⅱ 0-13 |
| Reverse gear | km/h | Ⅰ 0-5 Ⅱ 0-13 |
| Grade Ability | ° | 16° |
| Overall Dimension(LxWxH) | mm | 5500×1800×1900 |
| Min.Ground Clearance | mm | 220 |
| Wheel Base | mm | 2450 |
| Wheel Tread | mm | 1420 |
| Max.Dumping Height | mm | 1740 |
| Dumping Reach | mm | 945 |
| Rated Power | KW | 70 |
| Engine model | | YUCHAI |
| Tire Model | | 15/70-18 |
