● YUNNEI 4-cylinder 76KW engine.
● Special wheel-side reduction axle for construction machinery, with air-over-hydraulic caliper disc brakes.
The width of the whole machine is ≤ 1.8 meters, the height of the whole machine is ≤ 1.9 meters (up to the size of a simple shed), and the length of the whole machine is ≤ 5.6 meters.
● Narrower, lower, and shorter design, suitable for ultra-low and ultra-narrow passages.
● Standard 12-16.5 wear-resistant and puncture-proof tires for longer service life.
● Bucket blade made of wear-resistant 500 special steel plate.
● Bucket width can be customized according to user requirements.
● Standard exhaust gas water filtration device.
● Optional oxidation catalyst.
● Optional side dumping device.
● Optional tire protection chains.
| Project | Unit | Parameter |
|---|---|---|
| Bucket Capacity | m³ | 0.9 |
| Rated Load | T | 2.0 |
| Machine Weight | T | 5.0 |
| Max.Digging Force | KN | 48 |
| Max.Tractive Force | KN | 30 |
| Walking Speed | km/h | 0-13 |
| Forward gear | km/h | Ⅰ 0-5 Ⅱ 0-13 |
| Reverse gear | km/h | Ⅰ 0-5 Ⅱ 0-13 |
| Grade Ability | ° | 16° |
| Overall Dimension(LxWxH) | mm | 5540×1650×1800 |
| Min.Ground Clearance | mm | 220 |
| Wheel Base | mm | 2450 |
| Wheel Tread | mm | 1440 |
| Max.Dumping Height | mm | 1700 |
| Dumping Reach | mm | 945 |
| Rated Power | KW | 76 |
| Engine model | Yunnei | |
| Tire Model | 12-16.5 |
